Grandstream GWN7700P 5 Port Gigabit Unmanaged Ethernet PoE Switch
5 Port Gigabit Unmanaged Ethernet PoE Switch
| Brand - Networking: Grandstream |
| Switching Capacity: 10Gbps |
| PoE Support: Yes |
| 2.5G Ethernet Ports: 0 |
| 10G Ethernet Ports: 0 |
| SFP+ Ports: 0 |
| Gigabit Ethernet Ports: 5 |
| Enclousure: Metal | Wall Mountable |
The Grandstream GWN7700 series are unmanaged network switches that
provide a quick and cost-effective way to add high-speed Gigabit
connectivity to home offices and small/medium businesses. It requires no
configuration or installation, offers a desktop and wall-mountable
design, and provides auto MDI/MDIX to eliminate the need for crossover
cables. Each port supports auto-negotiation to allow the GWN7700 series
to recognize the link speed of any 10/100/1000Mbps network device and
intelligently adjust for compatibility and optimal performance. The PoE
(Power-over-Ethernet) models provide ports with IEEE 802.3af/at
compliant, smart dynamic PoE output to power IP phones, IP cameras,
Wi-Fi access points and other PoE endpoints. The plug-and-play GWN7700
series are the ideal unmanaged network switches for home offices and
small-to medium businesses.Features
- 5 Gigabit RJ45 ports, 4 port PoE+ output
- Auto MDI/MDIX crossover for all ports
- 802.3 af/at compliant Up to 30W on each port
- Broadcast/Multicast/Unicast Storm Control (fixed to 100Mbps) to monitor traffic levels
- QoS - Supports Default Strict Priority when present
- Green technology reduces power consumption
| Details | |
|---|---|
| Manufacturer's Code | GWN7700P |
| Gigabit Ports | 5 |
| PoE Ports | 4 |
| Enclosure | Metal |
| Mounting | Desktop/Wall Mount |
| Standards and Protocols | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at |
| Port Feature | 5× 10/100/1000Mbps RJ45 Ports, AUTO Negotiation, AUTO MDI/MDIX |
| Network Media | 1000Base-T/100Base-TX/10Base-T, Half/Full-Duplex |
| PoE Configuration | 1~4 Ports 802.3 af/at compliant, Up to 30 W on Each Port, Total 60W Power, Budget; Overload to cut off the lowest-priority port. Priority: Port 4 to Port 1 |
| LED Indicators | Per Port: Link/Activity Green, Per Device: Power Green |
| Mac Address Table | 2K |
| Switching Capacity | 10Gbps |
| Jumbo Frame | 9KB |
| Advanced Features | Mac Address Auto-Learning And Auto-Aging, IEEE 802.3x Flow Control 802.1p/DSCP, QoS, IGMP |
| Power Adapter | External 48V-53.5V/1.22A |
| Max Power Consumption by Base System | 2W (Excluding PoE output power) |
| Environmental | Operating Temperature: 0 to 40 °C (32 to 104 °F), Operating Humidity: 10% to 90% Non-condensing |
| Dimensions (L x W x H) | Unit:120 x 65 x 24.5mm |
| Weight | Unit 0.1KG |
